Poultry Manure Removal System — The Fast Track to a Cleaner, Healthier Chicken House

Ammonia burns eyes, damp litter breeds disease, and scraping manure by hand steals hours you can’t spare.
A neglected manure problem snowballs—sick birds, higher feed costs, and environmental fines.
Smart poultry manure removal systems automate scraping, belt conveyance, and waste storage so your flock stays healthy and your bottom line grows.

Why invest in an automatic poultry manure removal system?

An automatic manure belt or scraper removes chicken manure every day, drying droppings before ammonia forms, slashing labor costs, and preventing environmental pollution. The result is cleaner air, drier litter, and stronger weight‑gain performance—without constant manual work.

%poultry manure removal system belt conveyor

What Problems Do Manure Removal Systems Solve on a Modern Poultry Farm?

A gallinero generates roughly 100 g of chicken manure per hen per day. Left on the floor or beneath a cage, that dung releases ammonia, dampens litter, and attracts flies. Over time, high ammonia lowers feed intake and weight gain. It also corrodes metal, shortening cage life.

Modern manure removal systems attack these pain points:

• Health: Lower ammonia (< 10 ppm) improves lung function and feed conversion.
• Labor: Automatic poultry equipment cuts manual manure cleaning hours by 80 %.
• Environment: Frequent cleaning stops runoff, aligning with local manure‑management rules.

Transportador de estiércol interno | Eliminación de desechos avícolas de alta eficiencia y durabilidad
Optimize poultry waste management with our in-house manure conveyor. Featuring a hot-dip galvanized frame, corrosion resistance, anti-slip belt, and anti-deviation structure, it ensures efficient manure removal in complex farm conditions while maintaining hygiene and durability.

Transportador de estiércol interno

• La estructura principal está fabricada con acero galvanizado en caliente y soldado por perfiles, proporcionando alta resistencia a la corrosión y al óxido, además de gran durabilidad.
• El sistema de transmisión con rodillo de presión sobre la banda está diseñado para condiciones de trabajo exigentes, como estiércol diluido, agua de lluvia y superficies resbaladizas, evitando eficazmente el deslizamiento de la banda transportadora.
• El mecanismo de tensión de la cadena evita el salto de la misma, asegurando un funcionamiento estable.
• El sistema de cuchillas raspadoras de múltiples canales mejora la eficiencia en la limpieza de la banda de estiércol.
• El diseño del mango de la cuchilla raspadora es simple, práctico y garantiza una limpieza eficaz.
• Las estructuras antidesviación en los extremos frontal y trasero evitan el desalineamiento de la banda transportadora.
• La banda transportadora de caucho anular es altamente resistente al desgaste, anticorrosiva y duradera.

What Materials Make a Durable Poultry Manure Belt System?

• The system adopts well brand motor,with good overall strength and stable operation.
• Drive roller adopts high quality structural steel drive roller with hot dip zinc,corrosion resistant,stable operation and long service life.
• The belt pressing roller is a segmented rubber pressing roller,which can effectively prevent the deviation of the manure belt.
• The pressing roller is equipped with a pressing mechanism,which can effectively prevent the manure belt from slipping.
• Adopt double-channel PU material one-piece open mechanism of excrement cleaning scraper,close to the excrement belt,clean excrement scraping,convenient operation.
• Nylon spiral driven roller at the front can easily export chicken feathers and other sundry things without hurting the manure belt.
• The front end with high PVC inner scraper can effectively prevent chicken feathers and other sundries from entering the driven roller.
• PP material conveyor belt,wear resistance,anti aging,low friction coefficient.

Preguntas frecuentes

Can a manure belt system retrofit an old chicken farm?
Yes. Belts mount under existing cage rows; motors bolt to the end. Minor floor cutting may be needed for the cross conveyor.

How often should the manure belt run?
Typical schedule is twice daily for layers, once for broilers. Time can be set in the PLC based on flock density.

Does the manure scraper damage floor slats?
No. Scrapers glide on rails above the floor or pit surface—no contact with slats.

Which is better: belt or scraper systems?
Belts dry manure fast in battery cage systems; scrapers suit floor houses with deep‑pit storage.

What about power failures?
Systems include a manual hand‑crank or backup generator port to remove chicken manure in emergencies.

Is galvanized steel enough for lifelong corrosion?
HDG frames last 15 years; coastal farms may upgrade to 316 SS on critical parts.
